| Brand Name : | PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL |
| Model Number : | AMS 5645, UNS S32100 |
| Certification : | SGS, TUV, BV, ISO, MTC |
| Price : | Negotiations |
| Payment Terms : | T/T |
| Supply Ability : | 50000KGS/Month |
| Delivery Time : | Ex-stock for delivery: 3-7 days Production lead time: 30-60 days |
AMS 5645 Steel Forging Parts UNS S32100 Square Metal Rod
Size Range
| Round bar / Wire rod (Diameter): | 3.0mm to 1100mm |
| Square bar / Flat bar: | 5.0mm to 1000mm |
| Forging piece: | Stepped shafts with flanks / discs /tubes |
| Heavy/middle plate via hot rolled: | T6 - 100mm X W10 - 1000mm X L1500-10000mm |
Sheet steel via cold rolled: | T0.3 - 4.0mm X W6 - 1000mm X L1000 - 10000mm |
Steel strip via cold rolled: | T0.3 - 4.0mm X W5 - 150mm X L (or in coil form) |
| Length | Fixed length or random length or based on the customer's special requirement. |
Chemical Composition and standard
| Grade | AMS 5645 |
| standard | SAE AMS 5645S-2016 |
| Chemical Composition (weight%) | C (％): ≤ 0.08 Cu (%): ≤ 0.75 Mn (％): ≤ 2.00 N (%): ≤ 0.10 Si (％): ≤ 1.00 Ti (%): 5 x C ~ 0.70 P (％)≤: 0.040 S (％)≤: 0.030 Cr (％): 16.0 ~ 19.0 Ni (％): 8.00 ~ 12.0 Mo (%): ≤ 0.75 |
Mechanical Properties
AMS 5645 Stainless Steel Mechanical Properties
| Tensile strength,Rm/MPa: | ≥517 |
| Yield strength,Rp/MPa: | ≥206.8 |
| Elongation/%: | ≥30 |
| Reduction of area, ψ/%: | ≥40 |
| Impact, KV /J: | -- |
| Annealed hardness HBS: | Up to 50.8mm,incl 140~255 Over50.8mm ≤255 |
