| Brand Name : | PANGANGGROUP,ANSTEEL,TISCO,BAOSTEEL |
| Model Number : | DIN X3CrNiMoAl13-8-2, W-Nr 1.4534, PH 13-8Mo, UNS S13800 |
| Certification : | SGS,TUV,BV,ISO,MTC |
| Price : | Negotiations |
| Payment Terms : | T/T |
| Supply Ability : | 75000KGS/Month |
| Delivery Time : | Ex-stock for delivery: 3-7 days Production lead time: 30-60 days |
PH 13-8Mo DIN X3CrNiMoAl13-8-2 Stainless Steel Sheets Plates W-Nr
1.4534 Steel
Description
PH13-8Mo DIN X3CrNiMoAl13-8-2 Stainless Steel Sheets Plates W-Nr 1.4534 Steel is acid resistant special steel with martensitic structure, subjected to precipitation hardening, showing excellent mechanical properties - high hardness, strength and relatively high corrosion resistance, dynamic loads and cracking resistive.Compared to other high alloyed grades exhibiting corrosion resistance, PH13-8Mo DIN X3CrNiMoAl13-8-2 Stainless Steel Sheets Plates W-Nr 1.4534 Steel has much more limited acceptability of sulfur and phosphorus in its chemical composition, which demonstrates a relatively difficult manufacturing process and high purity and quality of steel.
All of PH13-8Mo DIN X3CrNiMoAl13-8-2 Stainless Steel Sheets Plates W-Nr 1.4534 Steel conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
Products Details
PH13-8Mo DIN X3CrNiMoAl13-8-2 Stainless Steel Sheets Plates W-Nr 1.4534 Steel
| Chemical Composition (weight%): | Mechanical Properties Under Final Heat Treatment: |
C (％): ≤ 0.05 Si (％): ≤ 0.10 Mn (％): ≤ 0.20 P (％)≤: 0.010 S (％)≤: 0.008 Cr (％): 12.3 ~ 13.2 Ni (％): 7.50 ~ 8.50 Mo (％): 2.00 ~ 2.50 Al (％): 0.90 ~ 1.35 N (%): ≤ 0.01 | Solution treatment temperature and cooling ways: 927 +/-15℃ Steel plate thickness /mm: 0.038~101.6 Tensile strength, σb≥/MPa: - Yield strength, σ0.2≥/MPa: - Elongation, δ≥ (％): - Hardness ≤|HRC: 38 Hardness ≤|HBS: 363 |
Applications:
PH13-8Mo DIN X3CrNiMoAl13-8-2 Stainless Steel Sheets Plates W-Nr
1.4534 Steel is often used in the aerospace, nuclear, and petrochemical industries for parts and
components subject to corrosion and heavy loads.
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging,
we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order
as the start of our cooperation, we can accept smaller quantities
at the first time. Of course, after the start, we will have further
and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing,
DHL/FedEx/UPS accounts can be used for sampling, and the courier
fee is borne by you.
|
|
