DIN X6CrAl13 Turbine Blade Steel W-Nr 1.4002
Description
All of DIN X6CrAl13 Turbine Blade Steel W-Nr 1.4002 conform to Military standard, nuclear power. 100% Ultrasonic test
ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
Products Details
DIN X6CrAl13 Turbine Blade Steel W-Nr 1.4002
| Chemical Composition (weight%): | Mechanical Properties Under Final Heat Treatment: |
| C (％): ≤ 0.08 Si (％)≤: 1.00 Mn (％)≤: 1.00 P (％)≤: 0.040 S (％)≤: 0.030 Cr (％): 12.0 ~ 14.0 Al (％): 0.10 ~ 0.30 | Condition: annealing Thickness/mm: - σb/MPa: 400～600 σ0.2≥/MPa: 250 δ5≥(％): 20 ψ≥(％): 60 Akv≥/J: - Hardness HBS30: ≤185 |
Applications:
DIN X6CrAl13 Turbine Blade Steel W-Nr 1.4002 used most often in the
has many structural and defense applications. Aircraft steel D6AC
Turbine Blade Steel martensitic used most often in thevehicle,
airplane, pressure vessel, power generations, etc.
| Technical Standard | Equivalent Grade |
| ISO/TS 15510(2003) | X6Cr13 |
| JIS G4303(2005) | SUS 405 |
| KS D3706(2006) | STS 405 |
| IS 6527(2001) | X04Cr13 |
| DIN EN 10088-1(2005) | X6Cr13/1.4000 |
| NF EN 10088-2(2005) | X6Cr13 |
| NF A35-573(1984) | Z6CA13 |
| BS 970-1(1996) | 403S17 |
| ASTM A959(2004) | 405/S40500 |
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging,
we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order
as the start of our cooperation, we can accept smaller quantities
at the first time. Of course, after the start, we will have further
and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing,
DHL/FedEx/UPS accounts can be used for sampling, and the courier
fee is borne by you.
|
|
