DIN EN 22Mo4 Structural Steel Round Bar W-Nr 1.5419
Description
DIN EN 22Mo4 Structural Steel Round Bar W-Nr 1.5419 has excellent machinability due to the silicon - calcium treatment and precise control of the sulphur content resulting in an excellent break-up of swarf, increasing feeds and speeds plus an increase in tool life for all machining operations.
Forging piece: stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm
Round bar / Wire rod (Diameter): 5.5mm to 800mm
Products Details
DIN EN 22Mo4 Structural Steel Round Bar W-Nr 1.5419
| Chemical Composition (weight%): | C (％): 0.18 ~ 0.25 Si (％): 0.20 ~ 0.40 Mn (％): 0.40 ~ 0.70 P (％)≤: 0.030 S (％)≤: 0.030 Cr (％): ≤ 0.30 Mo (％): 0.30 ~ 0.40 Ni (％): - |
| Mechanical Properties Under Final Heat Treatment: | Hot working temperature /℃: 1100～850 Heat treatment temperature /℃|annealing / normalizing : 660 ~ 700 Heat treatment temperature /℃|quenching: 880~920 oil Heat treatment temperature /℃|tempering: 600~660 HBS: 145 ~ 175 Tensile strength, (≥)| σb/MPa: 490～590 Yield strength, (≥)| σs/MPa: 295 Elongation, (≥)| δ5(%): 20.0 Impact strength, (≥)| AKV/J: 55 |
TYPICAL APPLICATIONS:
DIN EN 22Mo4 Structural Steel Round Bar W-Nr 1.5419 used most often in the bolts, nuts, fasteners, discs and turbine rotors in the energy, maritime and aerospace industries, as well as injection elements.
Equivalent Grade:
DIN EN 22Mo4, W-Nr 1.5419
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of DIN EN 22Mo4 Structural Steel Round Bar W-Nr 1.5419 and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging,
we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order
as the start of our cooperation, we can accept smaller quantities
at the first time. Of course, after the start, we will have further
and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing,
DHL/FedEx/UPS accounts can be used for sampling, and the courier
fee is borne by you.
|
|
