75Cr1 Structural Steel Flat Bar W-Nr 1.2003 Description

Mianyang Baoheng New Material Technology Co.,Ltd
Contact Now
    Buy cheap 75Cr1 Structural Steel Flat Bar W-Nr 1.2003 Description from wholesalers

    Buy cheap 75Cr1 Structural Steel Flat Bar W-Nr 1.2003 Description from wholesalers
    • Buy cheap 75Cr1 Structural Steel Flat Bar W-Nr 1.2003 Description from wholesalers
    • Buy cheap 75Cr1 Structural Steel Flat Bar W-Nr 1.2003 Description from wholesalers
    • Buy cheap 75Cr1 Structural Steel Flat Bar W-Nr 1.2003 Description from wholesalers

    75Cr1 Structural Steel Flat Bar W-Nr 1.2003 Description

    Ask Lasest Price
    Brand Name : PANGANGGROUP,ANSTEEL,TISCO,BAOSTEEL
    Model Number : 75Cr1, W-Nr 1.2003
    Certification : SGS,TUV,BV,ISO,MTC
    Price : Negotiations
    Payment Terms : T/T
    Supply Ability : 70000KGS/Month
    Delivery Time : Ex-stock for delivery: 2-5 days Production lead time: 32-45 days
    • Product Details
    • Company Profile

    75Cr1 Structural Steel Flat Bar W-Nr 1.2003 Description

    75Cr1 Structural Steel Flat Bar W-Nr 1.2003 Description


    Description


    75Cr1 Structural Steel Flat Bar W-Nr 1.2003 is a high carbon steel with a carbon content between 0.74% and 0.80%. The addition of chromium facilitates the heat treatment process and allows higher hardness to be achieved than the standard C75 Carbon Steel.75Cr1 Structural Steel Flat Bar W-Nr 1.2003 is a high carbon steel strip grade supplied in either hardened and tempered or annealed condition.15NiCuMoNb5 Structural Steel Flat Bar W-Nr 1.6368 VAR conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.


    Products Details


    Chemical Composition (weight%):
    C (%): 0.70 ~ 0.80
    Si (%): 0.25 ~ 0.50
    Mn (%): 0.60 ~ 0.80
    P (%)≤: 0.030
    S (%)≤: 0.030
    Cr (%): 0.30 ~ 0.40
    Mo (%): -
    V (%): -
    Mechanical Properties Under Final Heat Treatment:

    Hot working tenperature /℃: 1000~800
    Annealing temperature /℃: 700~720
    Hardness after annealing ≤HBW: 200
    Quenching temperature /℃: 770~800
    Cooling medium: water
    Common tempering temperature /℃: 180~200
    Hardness after tempering at temperature HRC|100℃: 66
    Hardness after tempering at temperature HRC|200℃: 60
    Hardness after tempering at temperature HRC|300℃: 52
    Hardness after tempering at temperature HRC|400℃: 43


    75Cr1 Structural Steel Flat Bar W-Nr 1.2003 Description


    Applications:


    75Cr1 Structural Steel Flat Bar W-Nr 1.2003 is used in the manufacturing knives, springs, doctor blades, clutch plates, agricultural tools, and shims.


    Equivalent Grade


    75Cr1

    W-Nr 1.2003


    75Cr1 Structural Steel Flat Bar W-Nr 1.2003 Description


    75Cr1 Structural Steel Flat Bar W-Nr 1.2003 Description

    75Cr1 Structural Steel Flat Bar W-Nr 1.2003 Description


    FAQ


    Q: How do you control the quality?


    A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.


    Q: Do you accept customization?


    A: Yes. If you have special requirements for products or packaging, we can make them for you.


    Q: Can you accept trial orders?


    A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.


    Q: How do I get samples?


    A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.
