UNS S13800 Alloy Steel Flat Bar UNS S13800 Stainless Steel Flat Bar S13800 Bar
Description
Our company provides UNS S13800 Alloy Steel Flat Bar UNS S13800 Stainless Steel Flat Bar S13800 Bar.All of UNS S13800 Alloy Steel Flat Bar UNS S13800 Stainless Steel Flat Bar S13800 Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
Products Details
UNS S13800 Alloy Steel Flat Bar UNS S13800 Stainless Steel Flat Bar S13800 Bar:Martensitic stainless steel,alloy is usually produced by VIM, followed by electroslag refining (ESR or VAR ) if necessary for special purpose.
| Chemical Composition (weight%) | ||
| MIN | MAX | |
| C | - | 0.05 |
| Si | - | 0.10 |
| Mn | - | 0.20 |
| P | - | 0.010 |
| S | - | 0.008 |
| Cr | 12.3 | 13.2 |
| Ni | 7.50 | 8.50 |
| Mo | 2.00 | 2.50 |
| Al | 0.90 | 1.35 |
| N | - | 0.01 |
| Mechanical Properties Under Final Heat Treatment | ||
| Solution treatment temperature and cooling ways: 1050 +/-15℃ | ||
| Ageing teated: H1000, 540℃, 4h, air cooling | ||
| MIN | MAX | |
| Tensile strength, σb MPa | 1410 | - |
| Yield strength, σ0.2 MPa | 1312 | - |
| Elongation, δ％ | 10.0 | - |
| Hardness HRC | 43 | - |
| Ageing teated: H1025, 550℃, 4h, air cooling | ||
| Tensile strength, σb MPa | 1275 | - |
| Yield strength, σ0.2 MPa | 1200 | - |
| Elongation, δ％ | 11.0 | - |
| Hardness HRC | 41 | - |
| Ageing teated: H1050, 565℃, 4h, air cooling | ||
| Tensile strength, σb MPa | 1200 | - |
| Yield strength, σ0.2 MPa | 1135 | - |
| Elongation, δ％ | 12.0 | - |
| Hardness HRC | 40 | - |
| Ageing teated: H1100, 595℃, 4h, air cooling | ||
| Tensile strength, σb MPa | 1030 | - |
| Yield strength, σ0.2 MPa | 930 | - |
| Elongation, δ％ | 14.0 | - |
| Hardness HRC | 34 | - |
| Ageing teated: H1150, 620℃, 4h, air cooling | ||
| Tensile strength, σb MPa | 930 | - |
| Yield strength, σ0.2 MPa | 625 | - |
| Elongation, δ％ | 14.0 | - |
| Hardness HRC | 30 | - |
ASTM XM-13 Stainless Steel Flat Bar ASTM XM-13 Flat Bar ASTM XM-13 Bar.
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of UNS S13800 Alloy Steel Flat Bar UNS S13800 Stainless Steel Flat Bar S13800 Bar and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging,
we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order
as the start of our cooperation, we can accept smaller quantities
at the first time. Of course, after the start, we will have further
and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing,
DHL/FedEx/UPS accounts can be used for sampling, and the courier
fee is borne by you.
Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement
|
|
