Black High Standard Turbine Blade Steel X5CrNiCu15-5 1.4545

Mianyang Baoheng New Material Technology Co.,Ltd
Contact Now
    Buy cheap Black High Standard Turbine Blade Steel X5CrNiCu15-5 1.4545 from wholesalers

    Buy cheap Black High Standard Turbine Blade Steel X5CrNiCu15-5 1.4545 from wholesalers
    • Buy cheap Black High Standard Turbine Blade Steel X5CrNiCu15-5 1.4545 from wholesalers
    • Buy cheap Black High Standard Turbine Blade Steel X5CrNiCu15-5 1.4545 from wholesalers

    Black High Standard Turbine Blade Steel X5CrNiCu15-5 1.4545

    Ask Lasest Price
    Brand Name : ANSTEEL,TISCO,BAOSTEEL,PANGANGGROUP
    Model Number : DIN X5CrNiCu15-5,DIN 1.4545l
    Certification : SGS,TUV,BV,ISO,MTC
    Price : Negotiations
    Payment Terms : T/T
    Supply Ability : 300000KGS/Month
    Delivery Time : Ex-stock for delivery: 3-5 days Production lead time: 30-35 days
    • Product Details
    • Company Profile

    Black High Standard Turbine Blade Steel X5CrNiCu15-5 1.4545

    X5CrNiCu15-5 1.4545 Turbine Blade Steel X5CrNiCu15-5 Round Bar 1.4545 Flat Bar


    Description


    Our company provides X5CrNiCu15-5 1.4545 Annealed / Quenched and Tempered Turbine Blade Steel X5CrNiCu15-5 Round Bar 1.4545 Milled / Cold working / Machined Flat Bar.

    All of X5CrNiCu15-5 1.4545 Annealed / Quenched and Tempered Turbine Blade Steel X5CrNiCu15-5 Round Bar 1.4545 Milled / Cold working / Machined Flat Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.


    Products Details


    X5CrNiCu15-5 1.4545 Annealed / Quenched and Tempered Turbine Blade Steel X5CrNiCu15-5 Round Bar 1.4545 Milled / Cold working / Machined Flat Bar.

    Chemical Composition (weight%):
    C≤ 0.07
    Si≤ 1.00
    Mn≤ 1.00
    P≤ 0.040
    S≤ 0.030
    Cr14.0 ~ 15.5
    Ni3.50 ~ 5.50
    Mo-
    Cu2.50 ~ 4.50
    Nb+Ta0.15 ~ 0.45
    Mechanical Properties Under Final Heat Treatment:
    Form: Bar, forge piece Condition: H900
    Tensile strength, σb/MPa1310
    Yield strength, σ0.2/MPa1170
    Elongation, δ (%)35
    Harndess: HRC40
    Form: Bar, forge piece Condition: H925
    σb/MPa1170
    σ0.2/MPa1070
    δ (%)L-10.0
    ψ (%)L-38.0
    Hardness HRC

    38

    Form: Bar, forge piece Condition: H1025

    σb/MPa1070
    σ0.2/MPa1000
    δ (%)12.0
    ψ (%)45
    Hardness HRC35
    Form: Bar, forge piece Condition: H1075
    σb/MPa1000
    σ0.2/MPa860
    δ (%)13.0
    ψ (%)45.0
    Hardness HRC32
    Form: Bar, forge piece Condition: H1100
    σb/MPa965
    σ0.2/MPa795
    δ(%)14;10
    ψ(%)45;29
    Hardness HRC31

    Black High Standard Turbine Blade Steel X5CrNiCu15-5 1.4545


    Equivalent Grade:


    X5CrNiCu15-5

    1.4545


    Black High Standard Turbine Blade Steel X5CrNiCu15-5 1.4545


    Black High Standard Turbine Blade Steel X5CrNiCu15-5 1.4545

    X5CrNiCu15-5 1.4545 Turbine Blade Steel X5CrNiCu15-5 Round Bar 1.4545 Flat Bar


    FAQ


    Q: How do you control the quality?


    A: We have professional inspectors to analyze the chemical composition of X5CrNiCu15-5 1.4545 Turbine Blade Steel X5CrNiCu15-5 Round Bar 1.4545 Flat Bar and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.


    Q: Do you accept customization?


    A: Yes. If you have special requirements for products or packaging, we can make them for you.


    Q: Can you accept trial orders?


    A: Our MOQ is usually 1 ton. However, if you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, we will have further and longer cooperation.


    Q: How do I get samples?


    A: Free samples are available for your inspection and testing, DHL/FedEx/UPS accounts can be used for sampling, and the courier fee is borne by you.


    Black High Standard Turbine Blade Steel X5CrNiCu15-5 1.4545
