ASTM XM-13 UNS S13800 Turbine Blade Steel ASTM XM-13 Round Bar S13800 Flat Bar
Description
Our company provides ASTM XM-13 UNS S13800 AOD / VOD / VAR + ESR /VIM refined Turbine Blade Steel ASTM XM-13 Forged / Hot Rolled / Cold Rolled Round Bar S13800 Flat Bar.
All of ASTM XM-13 UNS S13800 AOD / VOD / VAR + ESR /VIM refined Turbine Blade Steel ASTM XM-13 Forged / Hot Rolled / Cold Rolled Round Bar S13800 Flat Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
Products Details
ASTM XM-13 UNS S13800 AOD / VOD / VAR + ESR /VIM refined Turbine Blade Steel ASTM XM-13 Forged / Hot Rolled / Cold Rolled Round Bar S13800 Flat Bar.
| Chemical Composition (weight%): | |||||||||
C (％): ≤ 0.05 | Si (％): ≤ 0.10 | Mn (％): ≤ 0.20 | P (％)≤: 0.010 | S (％)≤: 0.008 | Cr (％):12.3 ~ 13.2 | Ni (％):7.50 ~ 8.50 | Mo(％):2.00 ~ 2.50 | Al (％):0.90 ~ 1.35 | N (%): ≤ 0.01 |
| Mechanical Properties Under Final Heat Treatment: | |||
Solution treatment temperature and cooling ways: 1050 +/-15℃ | |||
| Ageing teated: H1000, 540℃, 4h, air cooling | |||
| Tensile strength, σb≥/MPa: 1410 | Yield strength, σ0.2≥/MPa: 1312 | Elongation, δ≥(％): 10.0 | Hardness |HRC: 43 |
| Ageing teated: H1025, 550℃, 4h, air cooling | |||
| Tensile strength, σb≥/MPa: 1275 | Yield strength, σ0.2≥/MPa: 1200 | Elongation, δ≥(％): 11.0 | Hardness |HRC: 41 |
| Ageing teated: H1050, 565℃, 4h, air cooling | |||
| Tensile strength, σb≥/MPa: 1200 | Yield strength, σ0.2≥/MPa: 1135 | Elongation, δ≥(％): 12.0 | Hardness |HRC: 40 |
| Ageing teated: H1100, 595℃, 4h, air cooling | |||
| Tensile strength, σb≥/MPa: 1030 | Yield strength, σ0.2≥/MPa: 930 | Elongation, δ≥(％): 14.0 | Hardness |HRC: 34 |
| Ageing teated: H1150, 620℃, 4h, air cooling | |||
| Tensile strength, σb≥/MPa: 930 | Yield strength, σ0.2≥/MPa: 625 | Elongation, δ≥(％): 14.0 | Hardness |HRC: 30 |
Applications:
ASTM XM-13 UNS S13800 AOD / VOD / VAR + ESR /VIM refined Turbine Blade Steel ASTM XM-13 Forged / Hot Rolled / Cold Rolled Round Bar S13800 Flat Bar.Chemical equipment,Mechanical parts used in the condition of corrosion resistance,Bolt and nut,Pressure vessel.
Equivalent Grade:
ASTM XM-13
UNS S13800
ASTM XM-13 UNS S13800 AOD / VOD / VAR + ESR /VIM refined Turbine Blade Steel ASTM XM-13 Forged / Hot Rolled / Cold Rolled Round Bar S13800 Flat Bar.
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of ASTM XM-13 UNS S13800 Turbine Blade Steel ASTM XM-13 Round Bar S13800 Flat Bar and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging,
we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order
as the start of our cooperation, we can accept smaller quantities
at the first time. Of course, after the start, we will have further
and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing,
DHL/FedEx/UPS accounts can be used for sampling, and the courier
fee is borne by you.
|
|
