AISI 630 UNS S17400 Turbine Blade Steel AISI 630 Round Bar UNS S17400 Flat Bar
Description
Our company provides AISI 630 UNS S17400 Shot blasted / Ground / Peeled / Milled Turbine Blade Steel AISI 630 Round Bar UNS S17400 Flat Bar.All of AISI 630 UNS S17400 Shot blasted / Ground / Peeled / Milled Turbine Blade Steel AISI 630 Round Bar UNS S17400 Flat Bar. conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
Products Details
AISI 630 UNS S17400 Shot blasted / Ground / Peeled / Milled Turbine Blade Steel AISI 630 Round Bar UNS S17400 Flat Bar.
AISI 630 UNS S17400 is a corrosion resistant grade which is soft and ductile in the solution annealed condition. Medium to high strength, good toughness and strength is obtained by the appropriate ageing treatment.
| Chemical Composition (weight%): | |||||||||
C (％): ≤ 0.07 | Si (％): ≤ 1.00 | Mn (％): ≤ 1.50 | P (％)≤: 0.030 | S (％)≤: 0.015 | Cr (％):15.0 ~ 16.0 | Ni (％): 3.00 ~ 5.00 | Mo (％): ≤ 0.60 | Nb (％):0.15 ~ 0.35 | Cu (%):3.00 ~ 5.00 |
| Mechanical Properties Under Final Heat Treatment: | ||||||
Thickness/≤mm: 100 Condition of thermal treatment: +AT (Solution treatment) | ||||||
| Yield strength σ0.2≥/MPa: - | Tensile strength σb/MPa: ≤1200 | Elongation δ ≥(％): - | Elongation δ(transversal )≥(％): - | Elongation δ(transversal )≥(％): - | Impact absorbing power Akv≥/J : - | Hardness ≤HBS: 360 |
| Condition of thermal treatment: +P930 | ||||||
| Yield strength σ0.2≥/MPa: 720 | Tensile strength σb/MPa: 930~1100 | Elongation δ ≥(％): 16 | - | - | Impact absorbing power Akv≥/J : 40 | Hardness ≤HBS: - |
| Condition of thermal treatment: +P960 | ||||||
| Yield strength σ0.2≥/MPa: 790 | Tensile strength σb/MPa: 960~1160 | Elongation δ ≥(％): 12 | - | - | Impact absorbing power Akv≥/J : - | Hardness ≤HBS: - |
Equivalent Grade:
AMS 5643 5604 EN10088-3
EN/DIN1.4542 X5CrNiCuNb16.4 AFNOR Z6CNU17-O4
ASTM-A564 Grade 630 UNS S17400 JIS SUS630
17-4PH Turbine Blade Steel AMS5622 5643 Round Bar AISI 630 S40500 Flat Bar 1.4542 X5CrNiCuNb16-4 Bar
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of raw materials and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging,
we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1 ton. However, if you want to place an order
as the start of our cooperation, we can accept smaller quantities
at the first time. Of course, after the start, we will have further
and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing,
DHL/FedEx/UPS accounts can be used for sampling, and the courier
fee is borne by you.
|
|
