DIN EN X3CrNiCu18-9-4 1.4567 Stainless Steel Flat Bar X3CrNiCu18-9-4 Flat Bar 1.4567 Bar
Description
Our company provides DIN EN X3CrNiCu18-9-4 1.4567 Black Stainless Steel Flat Bar Bright X3CrNiCu18-9-4 Rrough Turned Flat Bar 1.4567 Bar.
All of DIN EN X3CrNiCu18-9-4 1.4567 Black Stainless Steel Flat Bar Bright X3CrNiCu18-9-4 Rrough Turned Flat Bar 1.4567 Bar. Conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
Products Details
DIN EN X3CrNiCu18-9-4 1.4567 Black Stainless Steel Flat Bar Bright X3CrNiCu18-9-4 Rrough Turned Flat Bar 1.4567 Bar
| Chemical Composition (weight%): | C (％): ≤ 0.040 |
| Si (％): ≤ 1.00 | |
| Mn (％): ≤ 2.00 | |
| P (％)≤: 0.045 | |
| S (％)≤: 0.030 | |
| Cr (％): 17.0 ~ 19.0 | |
| Ni (％): 8.50 ~ 10.5 | |
| Mo (％): - | |
| Cu (％): 3.00 ~ 4.00 | |
| N (％): ≤0.11 | |
| Mechanical Properties Under Final Heat Treatment: | Thickness Diameter (d)/≤mm: 160 |
| Hardness HBS: 215 | |
| Yield strength σ0.2≥/MPa: 175 | |
| Tensile strength σb/MPa: 450～650 | |
| Elongation δ(longitudinal )≥(％): 45 | |
| Elongation δ(transversal )≥(％): - | |
| Impact absorbing energy Akv≥/J|longitudinal: - | |
| Impact absorbing energy Akv≥/J|transversal: - | |
| Intergranular corrosion resistance tendency | condition of delivery: Yes | |
| Intergranular corrosion resistance tendency | condition of welding: Yes |
Applications:
DIN EN X3CrNiCu18-9-4 1.4567 Black Stainless Steel Flat Bar Bright X3CrNiCu18-9-4 Rrough Turned Flat Bar 1.4567 Bar
Bolt and nut,Chemical equipment,Mechanical parts used in the condition of corrosion resistance,Pressure vessel.
Equivalent Grade
DIN EN X3CrNiCu18-9-4 DIN EN 10088-1 2014
1.4567
DIN EN X3CrNiCu18-9-4 1.4567 Black Stainless Steel Flat Bar Bright X3CrNiCu18-9-4 Rrough Turned Flat Bar 1.4567 Bar
