| Brand Name : | PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL |
| Model Number : | DIN EN X2CrNiN18-10,1.4311 |
| Certification : | SGS,TUV,BV,ISO,MTC |
| Price : | Negotiations |
| Payment Terms : | T/T |
| Supply Ability : | 30000KGS/Month |
| Delivery Time : | Ex-stock for delivery: 3-7 days Production lead time: 50-60days |
DIN EN X2CrNiN18-10 1.4311 Stainless Steel Flat Bar X2CrNiN18-10 Flat Bar 1.4311 Bar
Description
Our company provides DIN EN X2CrNiN18-10 1.4311 Solution Treated Stainless Steel Flat Bar X2CrNiN18-10 Quenched and Tempered Flat Bar 1.4311 Peeled Bar.
All of DIN EN X2CrNiN18-10 1.4311 Solution Treated Stainless Steel Flat Bar X2CrNiN18-10 Quenched and Tempered Flat Bar 1.4311 Peeled Bar conform to Military standard, nuclear power. 100% Ultrasonic test ASTM E2375 /SAE AMS 2154 /SEP 1923 /GB/T 4162 /EN 10228-3.
Products Details
DIN EN X2CrNiN18-10 1.4311 Solution Treated Stainless Steel Flat Bar X2CrNiN18-10 Quenched and Tempered Flat Bar 1.4311 Peeled Bar
| Chemical Composition (weight%): | C (％): ≤ 0.030 |
| Si (％): ≤ 1.00 | |
| Mn (％): ≤ 2.00 | |
| P (％): ≤ 0.045 | |
| S (％)≤: 0.015 | |
| Cr (％): 17~19.5 | |
| Ni (％): 8.50~11.5 | |
| Mo (％): - | |
| N (％): 0.12 ~ 0.22 | |
| Mechanical Properties Under Final Heat Treatment: | Hot working temperature /℃: 1150～750 |
| Heat treatment temperature /℃|annealing / normalizing : - | |
| Heat treatment temperature /℃|quenching: 1050 -110 water/ Air | |
| Heat treatment temperature /℃|tempering: - | |
| Normal temperature and low temperature | Condition: Room temperature | |
| (≥)|σb/MPa: 540～740 | |
| (≥)|σs/MPa: - | |
| (≥)|δ5(%): 40 | |
| (≥)|ψ(％)≥: 50 | |
| (≥)|AKV(DVM)/J: 100 | |
| Normal temperature and low temperature | Condition: -80℃ | |
| (≥)|σb/MPa: 780 | |
| (≥)|σs/MPa: - | |
| (≥)|δ5(%): 35 | |
| (≥)|ψ(％)≥: - | |
| (≥)|AKV(DVM)/J: 96 |
Applications:
DIN EN X2CrNiN18-10 1.4311 Solution Treated Stainless Steel Flat Bar X2CrNiN18-10 Quenched and Tempered Flat Bar 1.4311 Peeled Bar
Alloy structural steels are widely used in the filed of ship,
vehicle, airplane, guided missile, weapons, railway, bridges,
pressure vessel, machine tools, mechanical components with a bigger
sectional size and so on.
Mechanical gears, gear shaft, main axis, valve rod
Mechanical parts - connecting rod, bolt and nut
Multidiameter shaft
Pressure vessel, seamless pipe
Equivalent Grade
DIN EN X2CrNiN18-10 DIN EN 10088-1 2014
1.4311
DIN EN X2CrNiN18-10 1.4311 Solution Treated Stainless Steel Flat Bar X2CrNiN18-10 Quenched and Tempered Flat Bar 1.4311 Peeled Bar
FAQ
Q: How do you control the quality?
A: We have professional inspectors to analyze the chemical composition of DIN EN X2CrNiN18-10 1.4311 Solution Treated Stainless Steel Flat Bar X2CrNiN18-10 Quenched and Tempered Flat Bar 1.4311 Peeled Bar and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, bending, set length, outer diameter and Wall thickness will be checked one by one.
Q: Do you accept customization?
A: Yes. If you have special requirements for products or packaging, we can make them for you.
Q: Can you accept trial orders?
A: Our MOQ is usually 1000 kg. However, if you want to place an
order as the start of our cooperation, we can accept smaller
quantities at the first time. Of course, after the start, we will
have further and longer cooperation.
Q: How do I get samples?
A: Free samples are available for your inspection and testing,
UPS/DHL/FedEx accounts can be used for sampling, and the courier
fee is borne by you.
|
|
