    G-NiCo15Cr10-AlTiMo W-Nr 2.4674 Alloy Round Bar AMS 5397 Square Bar

    Ask Lasest Price
    Brand Name : PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
    Model Number : AMS 5397, UNS N13100, W-Nr 2.4674, G-NiCo15Cr10-AlTiMo
    Certification : SGS, TUV, BV, ISO, MTC
    Price : Negotiations
    Payment Terms : T/T
    Supply Ability : 50000KGS/Month
    Delivery Time : Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
    • Product Details
    • Company Profile

    G-NiCo15Cr10-AlTiMo W-Nr 2.4674 Alloy Round Bar AMS 5397 Square Bar

    G-NiCo15Cr10-AlTiMo W-Nr 2.4674 Alloy Round Bar AMS 5397 Square Bar


    Product Information
    AMS 5397 is a high-temperature alloy, also known as Inconel X750. It is a nickel based alloy that contains chromium, molybdenum, aluminum, titanium, niobium, and small amounts of elements such as carbon, iron, manganese, and silicon. The main characteristics of AMS 5397 are its high-temperature strength, excellent corrosion resistance, and good processability. It is usually used to manufacture high-temperature and high-pressure components, such as aeroengines, gas turbines, rocket propellers and nuclear reactors. This material is also widely used in the manufacturing of high-pressure oil pipes and oil drilling equipment.
    AMS 5397 also has good wear resistance and fatigue resistance, making it suitable for manufacturing high load and high stress parts and components. In addition, this material also has good weldability and plasticity, making it suitable for manufacturing complex shaped parts and components.

    Size Range

    Round bar / Wire rod (Diameter):1.0 mm to 1500 mm
    Square bar / Flat bar: 1.0 mm to 500 mm
    Forging piece: Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
    Heavy/middle plate via hot rolled: T1.0 - 800 mm X W10 - 1000 mm X L100-1000 mm
    Sheet steel via cold rolled: T1.0 - 10 mm X W5 - 1000 mm X L100 - 1000 mm
    Steel strip via cold rolled: T1.0 - 10 mm X W5 - 800 mm X L (or in coil form)
    Length: Fixed length or random length or based on the customer's special requirement.


    Chemical Composition and standard

    G-NiCo15Cr10-AlTiMo / 2.4674

    AMS 5397

    DIN 17744-2002

    SAE AMS 5397F-2021


    C(%): 0.15~0.20
    Si(%): ≤0.20
    Mn(%): ≤0.20
    P(%): -
    S(%)≤: -
    Cr(%):
    8.00~11.0
    Ni(%): Remainder
    Mo(%): 2.00~4.00
    Co(%): 13.0~17.0
    Ti(%): 4.50~5.00
    Al(%): 5.00~6.00
    B(%): 0.01~0.02
    V(%): 0.70~1.20
    Zr(%): 0.03
    Fe(%): ≤1.00

    C(%): 0.15~0.20
    Si(%): ≤0.10
    Mn(%): ≤0.10
    P(%): 0.015
    S(%)≤: 0.015
    Cr(%):
    8.00~11.0
    Ni(%): Remainder
    Mo(%): 2.00~4.00
    Co(%): 13.0~17.0
    Ti(%): 4.50~5.00
    Al(%): 5.00~6.00
    Ti+Nb(%): 10.0~11.0
    B(%): 0.01~0.02
    V(%): 0.70~1.20
    Zr(%): 0.03~0.09
    Fe(%): ≤1.00


    G-NiCo15Cr10-AlTiMo W-Nr 2.4674 Alloy Round Bar AMS 5397 Square Bar

    AMS 5397 Mechanical Properties

    Tensile strength,Rm/MPa: ≥795
    Yield strength,Rp/MPa: ≥655
    Elongation, A/%: ≥5
    Reduction of area, ψ/%: --
    Impact, KV /J: --
    Hardness/ HRC: --

    Applications

    The key features of AMS 5397 are high temperature strength, excellent corrosion resistance and good machinability. It is commonly used to manufacture high temperature and high pressure components such as aircraft engines, gas turbines, rocket propulsion and nuclear reactors. The material is also widely used in the manufacture of high-pressure tubing and oil drilling equipment.
