1.7380 DIN 10CrMo9-10 Alloy Round Bar ASTM A182 F22 Flat Plate Steel

Mianyang Baoheng New Material Technology Co.,Ltd
Contact Now
    Buy cheap 1.7380 DIN 10CrMo9-10 Alloy Round Bar ASTM A182 F22 Flat Plate Steel from wholesalers

    Buy cheap 1.7380 DIN 10CrMo9-10 Alloy Round Bar ASTM A182 F22 Flat Plate Steel from wholesalers
    • Buy cheap 1.7380 DIN 10CrMo9-10 Alloy Round Bar ASTM A182 F22 Flat Plate Steel from wholesalers
    • Buy cheap 1.7380 DIN 10CrMo9-10 Alloy Round Bar ASTM A182 F22 Flat Plate Steel from wholesalers
    • Buy cheap 1.7380 DIN 10CrMo9-10 Alloy Round Bar ASTM A182 F22 Flat Plate Steel from wholesalers

    1.7380 DIN 10CrMo9-10 Alloy Round Bar ASTM A182 F22 Flat Plate Steel

    Ask Lasest Price
    Brand Name : PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
    Model Number : 10CrMo9-10, W-Nr 1.7380, ASTM A182 F22, BS 622, ISO F34, JIS SCMV4, NF 10CD9-10
    Certification : SGS, TUV, BV, ISO, MTC
    Price : Negotiations
    Payment Terms : T/T
    Supply Ability : 50000KGS/Month
    Delivery Time : Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
    • Product Details
    • Company Profile

    1.7380 DIN 10CrMo9-10 Alloy Round Bar ASTM A182 F22 Flat Plate Steel

    1.7380 DIN 10CrMo9-10 Alloy Round Bar ASTM A182 F22 Flat Plate Steel


    Product Information

    10CrMo9-10/1.7380 stainless steel is a low alloy steel containing 2.25% chromium. This stainless steel is widely used in oil field wellhead joints, hangers and globe valves. This grade is often used as the base metal for composite components.

    Size Range

    Round bar / Wire rod (Diameter): 3.0 mm to 500 mm
    Square bar / Flat bar: 3.0 mm to 500 mm
    Forging piece: Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
    Heavy/middle plate via hot rolled: T3 - 1000 mm X W10 - 1000 mm X L800-12000 mm
    Sheet steel via cold rolled: T5.0 - 10 mm X W10 - 1000 mm X L100 - 1000 mm
    Steel strip via cold rolled: T3 - 10 mm X W10 - 1000 mm X L (or in coil form)
    Length: Fixed length or random length or based on the customer's special requirement.


    Chemical Composition and standard


    10CrMo9-10/1.7380

    K21590/F22

    EN 10028-2-2009

    ASTM A182/A182M-2018


    C(%): 0.08~0.14
    Si(%): ≤0.5
    Mn(%): 0.4~0.8
    P(%)≤: 0.02
    S(%)≤: 0.01
    Cr(%):
    2.0~2.5
    Ni(%): -
    Mo(%): 0.9~1.1
    Cu(%): ≤0.3
    N(%): ≤0.012

    C(%): 0.05~0.15
    Si(%): ≤0.5
    Mn(%): 0.3~0.6
    P(%)≤: 0.04
    S(%)≤: 0.04
    Cr(%):
    2.0~2.5
    Ni(%): -
    Mo(%): 0.87~1.13

    1.7380 DIN 10CrMo9-10 Alloy Round Bar ASTM A182 F22 Flat Plate Steel

    10CrMo9-10/1.7380 Mechanical Properties

    Thickness
    (t)/mm

    Condition

    Tensile strength
    (Rm)/Mpa

    Yield strength
    (Rp)/MPa

    Elongation
    (A)/%

    Impact
    (KV )/J

    t≤16+NT480~630≥310≥18≥31
    16<t≤40+NT480~630≥300≥18≥31
    40<t≤60+NT480~630≥290≥18≥31
    60<t≤100+NT or +QT470~610≥280≥17≥27
    100<t≤150+QT460~610≥260≥17≥27
    150<t≤250+QT450~600≥250≥17≥27


    Applications

    10CrMo9-10/1.7380 is mainly used for steam boiler parts, steam turbine parts, boiler tube coils and superheater chambers, superheated steam pipes, steam coolers, stressed parts in the chemical industry, pressure vessels in energy devices, etc.
