| Brand Name : | PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL |
| Model Number : | AISI P20, UNS T51620, 40CrMnMo 7, W-Nr 1.2311 |
| Certification : | SGS, TUV, BV, ISO, MTC |
| Price : | Negotiations |
| Payment Terms : | T/T |
| Supply Ability : | 50000KGS/Month |
| Delivery Time : | Ex-stock for delivery: 3-7 days Production lead time: 30-60 days |
1.2311 DIN 40CrMnMo 7 Alloy Steel Flat Bar AISI P20 T51620 Tool Steel
Product Information
1.2311 is a plastic mold steel, suitable for use at high temperatures, mainly used for the frame of plastic moulds, hydroforming tools and plastic pressure molds. They are highly hardenable, temper resistant and high temperature resistant.
Size Range
Round bar / Wire rod (Diameter): 3.0 mm to 500 mm
Square bar / Flat bar: 3.0 mm to 500 mm
Forging piece: Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T3 - 1000 mm X W10 - 1000 mm X L1000-12000 mm
Sheet steel via cold rolled: T3 - 10 mm X W5 - 1000 mm X L100 - 1000 mm
Steel strip via cold rolled: T0.5 - 10 mm X W5 - 1000 mm X L (or in coil form)
Length: Fixed length or random length or based on the customer's special requirement.
Chemical Composition and standard
AISI P20/UNS T51620 | 40CrMnMo 7/1.2311 |
| ASTM A681-2008(R2015) | -- |
Mo(%): 0.30~0.55 Ni+Cu(%): ≤0.75 | C(％): 0.35~0.45 Mo(%): 0.15~0.25 |
40CrMnMo 7/1.2311 Mechanical Properties
Tensile strength,Rm/MPa: 965~1030
Yield strength,Rp/MPa: 827~862
Elongation/%: ≥20
Charpy Impact/J: 27.1~33.9
Hardness, Brinell/HB: ≤300
Applications
40CrMnMo 7/1.2311 mold steel is mainly used for plastic molds, mold bases, back plates, mold bases for plastic pressure molds, hydroforming molds, brackets, and mold bases.
