    1.2316 DIN X38CrMo 16 Stainless Steel Sheets Plates 1.2316 Hot Forged Parts

    Ask Lasest Price
    Brand Name : PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL
    Model Number : X38CrMo 16, W-Nr 1.2316
    Certification : SGS, TUV, BV, ISO, MTC
    Price : Negotiations
    Payment Terms : T/T
    Supply Ability : 50000KGS/Month
    Delivery Time : Ex-stock for delivery: 3-7 days Production lead time: 30-60 days
    • Product Details
    • Company Profile

    1.2316 DIN X38CrMo 16 Stainless Steel Sheets Plates 1.2316 Hot Forged Parts

    1.2316 DIN X38CrMo 16 Stainless Steel Sheets Plates 1.2316 Hot Forged Parts


    Product Information


    X38CrMo 16/1.2316 is used for chromium molybdenum steels hardened in oil and has very good hardenability and good robustness during heating. Due to the increased chromium content, the corrosion resistance of the steel increases. The steel has excellent wear resistance, good processability and polishability, and is delivered in a heat-treated state when used.


    Size Range


    Round bar / Wire rod (Diameter): 10.0 mm to 500 mm

    Square bar / Flat bar:10.0 mm to 500 mm

    Forging piece: Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.

    Heavy/middle plate via hot rolled: T3 - 1000 mm X W10 - 1000 mm X L1000-12000 mm

    Sheet steel via cold rolled: T3.0 - 10 mm X W5 - 1000 mm X L100 - 1000 mm

    Steel strip via cold rolled: T5.0 - 10 mm X W5 - 1000 mm X L (or in coil form)

    Length: Fixed length or random length or based on the customer's special requirement.


    Chemical Composition and standard



    ​X38CrMo 16/1.2316


    DIN 17350-1980


    C(%): 0.33~0.45
    Si(%):
    ≤1.0
    Mn(%): ≤1.5
    P(%)≤: 0.03
    S(%)≤: 0.03
    Cr(%): 15.5~17.5
    Ni(%):
    ≤1.0

    Mo(%): 0.8~1.3


    1.2316 DIN X38CrMo 16 Stainless Steel Sheets Plates 1.2316 Hot Forged Parts

    ​X38CrMo 16/1.2316 Mechanical Properties

    Dimension: d≤16

    Tensile strength,Rm/MPa: ≥695

    Yield strength,Rp/MPa: ≥116

    Elongation/%: ≥33

    Charpy Impact/J: ≥11


    Applications


    X38CrMo 16/1.2316 is used for precision stamping dies. Cold extrusion molding die. Cavitation molds, standard mold bases, SMC compression molds, blow molds, PET preform molds, plastic pipe and tube injection molds.
