W-Nr 2.4856 NiCr22Mo9Nb Alloy Round Bar Inconel 625 N06625 Cold Rolled Strip
Product Information
W-Nr 2.4856 NiCr22Mo9Nb excellent resistance against corrosion in
various corrosive substances
(phosphoric/nitric/sulfuric/hydrochloric acid)
also resistant to chloride induced tensile corrosion resistant
against alkalics and organic acids excellent resistance against
fissures, crevice/intercrystalline corrosion
Size Range
Round bar / Wire rod (Diameter): 10.0 mm to 1000 mm
Square bar / Flat bar: 8.0 mm to 500 mm
Forging piece: Stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T5 - 200 mm X W3 - 1000 mm X L1000-12000 mm
Sheet steel via cold rolled: T0.5 - 10 mm X W5 - 1000 mm X L300 - 1000 mm
Steel strip via cold rolled: T0.3 - 10.0 mm X W5 - 500 mm X L (or in coil form)
Length: Fixed length or random length or based on the customer's special requirement.
Chemical Composition and standard
NiCr22Mo9Nb/2.4856 | JIS NCF625 | UNS N06625/Incoloy 625 |
| DIN 17744-2020 | JIS G 4901-2008 | ASTM B443-2000(R2014) |
Mo(%): 8.0~10.0 Cu(%): ≤0.5 Ti(%): ≤0.4 Co(%): ≤1.0 Al(%): ≤0.4 Nb+Ta: 3.15~3.45 Fe(%): ≤5.0 | C(％): ≤0.1 Mo(%): 8.0~10.0 Cu(%): -- Ti(%): ≤0.4 Co(%): -- Al(%): ≤0.4 Nb+Ta: 3.15~3.45 Fe(%): ≤5.0 | C(％): ≤0.1 Mo(%): 8.0~10.0 Cu(%): -- Ti(%): ≤0.4 Co(%): ≤1.0 Al(%): ≤0.4 Nb+Ta: 3.15~3.45 Fe(%): ≤5.0 |
W-Nr 2.4856 NiCr22Mo9Nb Mechanical Properties
Suitable size /mm: 2.5~100
Tensile strength, σb/≥ MPa: ≥830
Yield strength, σ0.2/≥ MPa: ≥415
Elongation, δ ≥(％): ≥30
Hardness | HBW ≤: -
Suitable size /mm: 100 ~ 250
Tensile strength, σb/≥ MPa: ≥760
Yield strength, σ0.2/≥ MPa: ≥345
Elongation, δ ≥(％): ≥30
Hardness | HBW ≤: -
Applications
W-Nr 2.4856 NiCr22Mo9Nb superalloy is commonly used in piping and exhaust systems, expansion joints, furnace equipment and valve components.
